Characteristics
- High bandwidth and excellent communication transmission property
- Good performance of crush resistance
- Simple structure, light weight and high practicability
- Easily strip and splice, simplify the installation and maintenance.
- Low smoke, zero halogen, flame retardant, eco-friendly.
Technical Parameters
Cable Type | Cable Diameter (mm) |
Cable Weight (kg/km) |
Tensile Strength Long/Short term (N) |
Crush Resistance Long/Short term (N/100cm) |
Bending Radius Dynamic/Static (mm) |
Attenuation(dB/km) 1310/1550nm |
Storage Operating Temperature |
GJXFX/GFXH 1core |
(2.0±0.2)*(3.0±0.2) | 8.5 | 30/60 | 300/1000 | 30/60 | ≤0.40/0.30 | -20℃~+60℃ |
GJXFX/GFXH 2cores |
(2.0±0.2)*(3.0±0.2) | 9.5 | |||||
GJXFX/GFXH 4cores |
(2.0±0.2)*(4.0±0.2) | 10 |
